PERFORMANCE DATA & PRESSURE CURVES
LEGEND
TC – Total Cooling Capacity, kW
SC – Sensible Capacity, kW
PI – Power Input, kW
WB – Wet Bulb Temp., (
o
C)
DB – Dry Bulb Temp., (
o
C)
ID – Indoor
OU – Outdoor
5.2.2 Heating Capacity (kW)
ENTERING AIR DB ID COIL(
O
c)
15 20 25
ENTERING WB
OD COIL(
o
C)
TH Pl TH Pl TH Pl
-10 1.89 0.88 1.82 0.94 1.75 0.98
-7 2.03 0.90 1.96 0.95 1.89 1.00
-2 2.16 0.91 2.09 0.97 2.02 1.02
2 2.63 0.96 2.52 1.02 2.41 1.08
6 3.71 1.03
3.60 1.10
3.47 1.17
10 4.03 1.09 3.92 1.16 3.82 1.24
15 4.36 1.13 4.25 1.22 4.14 1.30
20 4.59 1.17 4.48 1.27 4.36 1.36
LEGEND
TH – Total Heating Capacity, kW
PI – Power Input, kW
WB – Wet Bulb Temp., (
o
C)
DB – Dry Bulb Temp., (
o
C)
ID – Indoor
OU – Outdoor
5.2.3 Curves
Cooling
