Airwell DAF009 - 5.3 YIF018 Performance Data

PERFORMANCE DATA & PRESSURE CURVES
5.3 YIF018
5.3.1 Cooling Capacity (kW)
Data
Entering Air WB/DB ID Coil(
o
C)
15/21 17/24 19/27 21/29 23/32
TC
5.10 5.40 5.65 5.90 6.10
15 SC
3.30 3.50 3.68 3.60 3.66
PI
1.49 1.49 1.50 1.50 1.51
TC
5.05 5.35 5.60 5.85 6.05
20 SC
3.60 3.83 4.04 3.93 4.01
PI
1.61 1.62 1.63 1.64 1.64
TC
4.85 5.20 5.50 5.75 5.95
25 SC
3.21 3.43 3.63 3.57 3.66
PI
1.74 1.75 1.77 1.78 1.79
TC
4.55 4.90 5.30 5.50 5.70
30 SC
3.05 3.29 3.55 3.48 3.62
PI
1.88 1.90 1.93 1.94 1.95
TC
4.20 4.55
5.00
5.25 5.45
35 SC
2.87 3.12
3.41
3.37 3.51
PI
2.03 2.07
2.10
2.12 2.13
TC
3.80 4.15 4.60 4.85 5.05
40 SC
2.66 2.93 3.23 3.18 3.33
PI
2.19 2.23 2.27 2.29 2.31
TC
3.30 3.65 4.10 4.35 4.55
46 SC
2.42 2.69 3.02 2.97 3.11
PI
2.40 2.44 2.49 2.52 2.55
Entering Air DB
OD Coil(
o
C)
LEGEND
TC – Total Cooling Capacity, kW
SC – Sensible Capacity, kW
PI – Power Input, kW
WB – Wet Bulb Temp., (
o
C)
DB – Dry Bulb Temp., (
o
C)
ID – Indoor
OU – Outdoor
5-6 SM YIF 2-A.1 GB
