PERFORMANCE DATA & PRESSURE CURVES
5-16 SM YIF 2-A.1 GB
Data
Entering Air WB/DB ID Coil(
o
C)
15/21 17/24 19/27 21/29 23/32
TC
12.24 12.96 13.56 14.16 14.64
15 SC
7.90 8.38 8.83 8.62 8.77
PI
3.76 3.77 3.77 3.79 3.81
TC
12.12 12.84 13.44 14.04 14.52
20 SC
8.64 9.18 9.70 9.42 9.63
PI
4.07 4.09 4.11 4.13 4.14
TC
11.64 12.48 13.20 13.80 14.28
25 SC
7.68 8.22 8.70 8.54 8.76
PI
4.39 4.43 4.47 4.50 4.51
TC
10.92 11.76 12.72 13.20 13.68
30 SC
7.30 7.88 8.51 8.34 8.68
PI
4.75 4.81 4.87 4.91 4.92
TC
10.08 10.92
12.00
12.60 13.08
35 SC
6.87 7.47
8.17
8.07 8.41
PI
5.14 5.22
5.30
5.34 5.36
TC
9.12 9.96 11.04 11.64 12.12
40 SC
6.38 7.03 7.73 7.61 7.98
PI
5.53 5.62 5.72 5.78 5.82
TC
7.92 8.76 9.84 10.44 10.92
46 SC
5.80 6.43 7.25 7.11 7.44
PI
6.07 6.17 6.28 6.36 6.42
Entering Air DB
OD Coil(
o
C)
LEGEND
TC – Total Cooling Capacity, kW
SC – Sensible Capacity, kW
PI – Power Input, kW
WB – Wet Bulb Temp., (
o
C)
DB – Dry Bulb Temp., (
o
C)
ID – Indoor
OU – Outdoor
5.7.2 Heating Capacity (kW)
