PERFORMANCE DATA & PRESSURE CURVES
LEGEND
TC – Total Cooling Capacity, kW
SC – Sensible Capacity, kW
PI – Power Input, kW
WB – Wet Bulb Temp., (
o
C)
DB – Dry Bulb Temp., (
o
C)
ID – Indoor
OU – Outdoor
5.8.2 Heating Capacity (kW)
ENTERING AIR DB ID COIL(
O
c)
15 20 25
ENTERING WB
OD COIL(
o
C)
TH Pl TH Pl TH Pl
-10 9.71 4.40 9.34 4.69 8.97 4.92
-7 10.45 4.51 10.08 4.76 9.71 5.02
-2 11.10 4.57 10.73 4.84 10.36 5.12
2 13.51 4.79 12.95 5.09 12.40 5.39
6 19.06 5.14
18.50 5.50
17.85 5.84
10 20.72 5.43 20.17 5.80 19.61 6.20
15 22.39 5.67 21.83 6.11 21.28 6.49
20 23.59 5.83 23.03 6.33 22.39 6.82
LEGEND
TH – Total Heating Capacity, kW
PI – Power Input, kW
WB – Wet Bulb Temp., (
o
C)
DB – Dry Bulb Temp., (
o
C)
ID – Indoor
OU – Outdoor
5.8.3 Curves
Cooling
