PRODUCT DATA SHEET
SM FBFRPM 1-A.0 GB
(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN 14511.
(2) Airflow in ducted units; at nominal external static pressure.
(3) Sound power in ducted units is measured at air discharge.
(4) Sound pressure level measured at 1 meter distance from unit.
2.4 FBF036 / GCN 37NRCT
Model Indoor Unit FBF036
Model Outdoor Unit GCN 37NRCT
Installation Method of Pipe Flared
Characteristics Units Cooling Heating
Capacity
(1)
Btu/hr 33,440 34,800
kW 9.80 10.20
Power input
(1)
kW 3.32 3.40
EER (Cooling) or COP(Heating)
(1)
W/W 2.95 3.00
Energy efficiency class C D
Power supply V/Ph/Hz 400V/3N/50Hz
Rated current A 3x6.5 3x6.9
Starting current A 43
Circuit breaker rating A 3 x 16
INDOOR
Fan type & quantity Centrifugal x 3
Fan speeds H/M/L RPM 1320x1220x1140
Air flow
(2)
H/M/L m3/hr 1240/1145/1070
External static pressure Min-Max Pa N/A
Sound power level
(3)
H/M/L dB(A) 64/62/60
Sound pressure level
(4)
H/M/L dB(A) 53/51/49
Moisture removal l/hr 4.0
Condensate drain tube I.D mm 2
Dimensions WxHxD mm 1280x660x206
Weight kg 34
Package dimensions WxHxD mm 1379x744x310
Packaged weight kg 42
Units per pallet units 6
Stacking height units 3
OUTDOOR
Refrigerant control Capillary tube ( restrictor for heating)
Compressor type, model Rotary
Fan type & quantity Axial & 2
Fan speeds H/L RPM 1150
Air flow H/L m3/hr 4150
Sound power level H/L dB(A) 70
Sound pressure level
(4)
H/L dB(A) 62
Dimensions WxHxD mm 900x970x340
Weight kg 87
Package dimensions WxHxD mm 985x1020x435
Packaged weight kg 91
Units per pallet units 6
Stacking height units 2
Refrigerant type R410A
Refrigerant chargless distance kg/m 2.45/15
Additional charge per 1 meter g/m 30
Connections between units
Liquid line In.(mm) 3/8"(9.53)
Suction line In.(mm) 3/4"(19.05)
Max .tubing length m. Max.50
Max .height
difference
m. Max.25
Operation control type Remote control
Heating elements kW
Others Crankcase heater (50W), 3 Phase Protector
