PRODUCT DATA SHEET
SM FBFRPM 1-A.0 GB
(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN 14511.
(2) Airflow in ducted units; at nominal external static pressure.
(3) Sound power in ducted units is measured at air discharge.
(4) Sound pressure level measured at 1 meter distance from unit.
2.5 FBF045 / YDF047
Model Indoor Unit FBF045
Model Outdoor Unit YDF047
Installation Method of Pipe Flared
Characteristics Units Cooling Heating
Capacity
(1)
Btu/hr 43,670 51,180
kW 12.8 15.00
Power input
(1)
kW 4.56 4.55
EER (Cooling) or COP(Heating)
(1)
W/W 2.81 3.30
Energy efficiency class C C
Power supply V/Ph/Hz 400V/3N/50Hz
Rated current A 3 x 8.6 3 x 8.3
Starting current A 49
Circuit breaker rating A 3 x 20
INDOOR
Fan type & quantity Centrifugal x 4
Fan speeds H/M/L RPM 1170/1060/990
Air flow
(2)
H/M/L m3/hr 1940/1760/1640
External static pressure Min-Max Pa N/A
Sound power level
(3)
H/M/L dB(A) 63/61/59
Sound pressure level
(4)
H/M/L dB(A) 52/50/48
Moisture removal l/hr 4.8
Condensate drain tube I.D mm 25
Dimensions WxHxD mm 1670x680x244
Weight kg 52
Package dimensions WxHxD mm 1764x760x343
Packaged weight kg 62
Units per pallet units 3
Stacking height units 3
OUTDOOR
Refrigerant control Capillary tube ( restrictor for heating)
Compressor type, model Scroll
Fan type & quantity Axial & 2
Fan speeds H/L RPM 1220
Air flow H/L m3/hr 4500
Sound power level H/L dB(A) 72
Sound pressure level
(4)
H/L dB(A) 64
Dimensions WxHxD mm 900x970x340
Weight kg 91
Package dimensions WxHxD mm 985x1020x435
Packaged weight kg 95
Units per pallet units 6
Stacking height units 2
Refrigerant type R410A
Refrigerant chargless distance kg/m 2.45/15
Additional charge per 1 meter g/m 30
Connections between units
Liquid line In.(mm) 3/8"(9.53)
Suction line In.(mm) 3/4"(19.05)
Max .tubing length m. Max.50
Max .height
difference
m. Max.25
Operation control type Remote control
Heating elements kW
Others Crankcase heater (50W), 3 Phase Protector
