PRODUCT DATA SHEET
SM FBFRPM 1-A.0 GB
2.6 FBF060 / YCF055
Model Indoor Unit FBF060
Model Outdoor Unit YCF055
Installation Method of Pipe Flared
Characteristics Units Cooling Heating
Capacity
(1)
Btu/hr 48,450 56,300
kW 14.20 16.50
Power input
(1)
kW 5.02 5.63
EER (Cooling) or COP(Heating)
(1)
W/W 2.83 2.93
Energy efficiency class C D
Power supply V/Ph/Hz 400V/3N/50Hz
Rated current A 3 x 9.5 3 x 10.4
Starting current A 66
Circuit breaker rating A 3 x 25
INDOOR
Fan type & quantity Centrifugal x 4
Fan speeds H/M/L RPM 1170/1060/990
Air flow
(2)
H/M/L m3/hr 1940/1760/1640
External static pressure Min-Max Pa N/A
Sound power level
(3)
H/M/L dB(A) 63/61/59
Sound pressure level
(4)
H/M/L dB(A) 52/50/48
Moisture removal l/hr 5.6
Condensate drain tube I.D mm 25
Dimensions WxHxD mm 1670x680x244
Weight kg 52
Package dimensions WxHxD mm 1764x760x343
Packaged weight kg 62
Units per pallet units 3
Stacking height units 3
OUTDOOR
Refrigerant control Capillary tube ( restrictor for heating)
Compressor type, model Scroll
Fan type & quantity Axial & 2
Fan speeds H/L RPM 860
Air flow H/L m3/hr 5500
Sound power level H/L dB(A) 71
Sound pressure level
(4)
H/L dB(A) 62
Dimensions WxHxD mm 900x1255x340
Weight kg 110
Package dimensions WxHxD mm 985x1395x435
Packaged weight kg 120
Units per pallet units 3
Stacking height units 1
Refrigerant type R410A
Refrigerant chargless distance kg/m 4.05/15
Additional charge per 1 meter g/m 40
Connections between units
Liquid line In.(mm) 1/2"(12.7)
Suction line In.(mm) 7/8"(22.2)
Max .tubing length m. Max.50
Max .height
difference
m. Max.25
Operation control type Remote control
Heating elements kW
Others Crankcase heater (50W), 3 Phase Protector
(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN 14511.
(2) Airflow in ducted units; at nominal external static pressure.
(3) Sound power in ducted units is measured at air discharge.
(4) Sound pressure level measured at 1 meter distance from unit.
