2-1
PRODUCT DATA SHEET
SM FBFRPM 1-A.0 GB
2. PRODUCT DATA SHEET
2.1 FBF030 / YDF030
Model Indoor Unit FBF030
Model Outdoor Unit YDF030
Installation Method of Pipe Flared
Characteristics Units Cooling Heating
Capacity
(1)
Btu/hr 28,500 30,700
kW 8.35 9.00
Power input
(1)
kW 2.88 2.80
EER (Cooling) or COP(Heating)
(1)
W/W 2.90 3.21
Energy efficiency class C C
Power supply V/Ph/Hz 220-240V/1/50Hz
Rated current A 13.0 12.4
Starting current A 64
Circuit breaker rating A 25
INDOOR
Fan type & quantity Centrifugal x 3
Fan speeds H/M/L RPM 1320x1220x1140
Air flow
(2)
H/M/L m3/hr 1240/1145/1070
External static pressure Min-Max Pa N/A
Sound power level
(3)
H/M/L dB(A) 64/62/60
Sound pressure level
(4)
H/M/L dB(A) 53/51/49
Moisture removal l/hr 3.2
Condensate drain tube I.D mm 25
Dimensions WxHxD mm 1280x660x206
Weight kg 34
Package dimensions WxHxD mm 1379x744x310
Packaged weight kg 42
Units per pallet units 6
Stacking height units 3
OUTDOOR
Refrigerant control Capillary tube ( restrictor for heating)
Compressor type, model Rotary
Fan type & quantity Axial & 1
Fan speeds H/L RPM 850
Air flow H/L m3/hr 3150
Sound power level H/L dB(A) 69
Sound pressure level
(4)
H/L dB(A) 59
Dimensions WxHxD mm 900x860x340
Weight kg 78
Package dimensions WxHxD mm 985x907x435
Packaged weight kg 82
Units per pallet units 6
Stacking height units 2
Refrigerant type R410A
Refrigerant chargless distance kg/m 2.20/15
Additional charge per 1 meter g/m 30
Connections between units
Liquid line In.(mm) 3/8"(9.53)
Suction line In.(mm) 5/8"(15.88)
Max .tubing length m. Max.50
Max .height
difference
m. Max.25
Operation control type Remote control
Heating elements kW
Others
Crankcase heater (50W), ASK – Factory
Option
(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN 14511.
(2) Airflow in ducted units; at nominal external static pressure.
(3) Sound power in ducted units is measured at air discharge.
(4) Sound pressure level measured at 1 meter distance from unit.
