PRODUCT DATA SHEET
SM SX DCI 1-A.3 GB
2. PRODUCT DATA SHEET
2.1 SX 9 DCI R410A
Model Indoor Unit SX 9 DCI
Model Outdoor Unit GC 9 DCI
Installation Method of Pipe Flared
Characteristics Units Cooling Heating
Capacity
(1)
Btu/hr 8530(4780~12280) 10920(5120~15350)
kW 2.5(1.4-3.6) 3.2(1.5~4.5)
Power input
(1)
kW 0.62(0.42-1.1) 0.93(0.4~1.6)
EER (Cooling) or COP(Heating)
(1)
W/W 4.03 3.41
Energy efficiency class
AB
Power supply V/Ph/Hz 220-240V/Single/50Hz
Rated current A 2.7 4.1
Starting current A 10.5
Circuit breaker rating A 35
INDOOR
Fan type & quantity
Centrifugal x 2
Fan speeds H/M/L RPM 760/670/500
Air flow
(2)
H/M/L m3/hr 400/350/300
External static pressure Min-Max Pa 0
Sound power level
(3)
H/M/L dB(A) 50/49/47
Sound pressure level
(4)
H/M/L dB(A) 39/37/35
Moisture removal l/hr 1
Condenstate drain tube I.D Mm 16
Dimensions WxDxH Mm 820*190*630
Weight Kg 21
Package dimensions WxDxH Mm 890*280*710
Package weight
Kg 25
Units per pallet Units 14units per pallet
Units stacking Units 7 levels
OUTDOOR
Refrigerant control
EEV
Compressor type,model
Single Rotary,DC Inverter,Panasonic 5RS102XAB
Fan type & quantity
Propeller(direct) x 1
Fan speeds H/L RPM 830
Air flow H/L m3/hr 1780
Sound power level H/L dB(A) 61
Sound pressure level
(4)
H/L dB(A) 51
Dimensions WxDxH Mm 795*290*610
Weight Kg 38
Package dimensions WxDxH Mm 945*395*655
Packaged weight Kg 42
Units per pallet Units 9
Stacking height Units 3 levels
Refrigerant type
R410A
Refrigerant chargless distance kg/m 1.10kg/7.5m
Additional charge per 1 meter g/m No Need
Connections between units
Liquid line In.(mm) 1/4"(6.35)
Suction line In.(mm) 3/8"(9.53)
Max.tubing length m. Max.20
Max.height difference m. Max.10
Operation control type
Remote control
Heating elements (Option) kW
Others
(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN 14511.
(2) Airflow in ducted units; at nominal external static pressure.
(3) Sound power in ducted units is measured at air discharge.
(4) Sound pressure level measured at 1 meter distance from unit.
