Airwell GC 24 DCI User Manual

13-5
EXPLODED VIEWS AND SPARE PARTS LISTS
SM SX DCI 1-A.3 GB
13.5 Indoor Unit: SX 24, 30 DCI
No. Part No. Description Qty
1 484002 Grille 1
2 221554 Air Filter 2
3 373244 Right panel 1
4 307982 Frame Asy 1
5 371071-72 Display panel 1
6 470680004 Evaporator Assy 1
7 370280 Air Outlet Assy 1
8 285032 Draining Hose 1
9 372336 Horizontal louver front 1
9 372337 Horizontal louver back 1
10 371255 Vert. Louver 12
11 372340 Fan cover 1
12 293322 Fan 1
13 307980 Back panel 1
14 466236 Installation Plate 1
15 382333 Base panel EPS 1
16 466100005 Motor 1
17 323422 Motor support 1
18 436665 Step Motor 1
18 263034 Swing motor 1
20 455000603 Capacitor 1
21 234213 Display 1
22 373246 Fan frame 1
23 452935900 DCI storm 1
24 438082 Thermistor indoor coil 1
25 438413 Thermistor 1
26 311036 Storm panel 1
27 391508 DConnect wire 1
29 436609R Remote control 1
30 373245 Left panel 1
33 4521029 Spring clip 1
