PRODUCT DATA SHEET
SM SX DCI 1-A.3 GB
2.3 SX 18 DCI R410A
Model Indoor Unit SX 18 DCI
Model Outdoor Unit GC 18 DCI
Installation Method of Pipe Flared
Characteristics Units Cooling Heating
Capacity
(1)
Btu/hr 17000(5120-20460) 20460(5120-24550)
kW 5.0(1.5-6.0) 5.8(1.5~7.2)
Power input
(1)
kW 1.65(0.5-2.1) 1.69(0.45-2.1)
EER (Cooling) or COP(Heating)
(1)
W/W 3.03 3.43
Energy efficiency class
BB
Power supply V/Ph/Hz 220-240V/Single/50Hz
Rated current A 7.2 7.7
Starting current A 10.5
Circuit breaker rating A 35
INDOOR
Fan type & quantity
Centrifugal x 2
Fan speeds H/M/L RPM 1050/950/700
Air flow
(2)
H/M/L m3/hr 870/750/600
External static pressure Min-Max Pa 0
Sound power level
(3)
H/M/L dB(A) 65/60/56
Sound pressure level
(4)
H/M/L dB(A) 51/48/45
Moisture removal l/hr 2
Condenstate drain tube I.D mm 16
Dimensions WxDxH mm 1200*190*630
Weight kg 30
Package dimensions WxDxH mm 1270*280*710
Package weight
kg 35
Units per pallet units 7units per pallet
Units stacking units 7 levels
OUTDOOR
Refrigerant control
EEV
Compressor type,model
Scroll compressor 5CS130XCC03
Fan type & quantity
Propeller(direct) x 1
Fan speeds H/L RPM 920
Air flow H/L m3/hr 2160
Sound power level H/L dB(A) 63
Sound pressure level
(4)
H/L dB(A) 53
Dimensions WxDxH mm 795*290*610
Weight kg 39
Package dimensions WxDxH mm 945*395*655
Packaged weight kg 43
Units per pallet Units 9
Stacking height units 3 levels
Refrigerant type
R410A
Refrigerant chargless distance kg/m 1.50kg/7.5m
Additional charge per 1 meter g/m No Need
Connections between
units
Liquid line In.(mm) 1/4"(6.35)
Suction line In.(mm) 1/2"(12.7)
Max.tubing length m. Max.30
Max.height difference m. Max.10
Operation control type
Remote control
Heating elements (Option) kW
Others
(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN 14511.
(2) Airflow in ducted units; at nominal external static pressure.
(3) Sound power in ducted units is measured at air discharge.
(4) Sound pressure level measured at 1 meter distance from unit.
