PRODUCT DATA SHEET
SM FLODCI 2-A.4 GB
2.5 FLO 30 DCI
Model Indoor Unit FLO- 30
Model Outdoor Unit GC 30
Installation Method of Pipe Flared
Characteristics Units Cooling Heating
Capacity
(1)
Btu/hr 26620(5100~30035) 29010 (5100~32420)
kW 7.8 (1.50~8.8) 8.5 (1.5~9.5)
Power input
(1)
kW 2.59 (0.50~3.1) 2.65 (0.5~3.2)
EER (Cooling) or COP(Heating)
(1)
W/W 3.01 3.21
Energy efficiency class B C
Power supply V/Ph/Hz 220-240V/Single/50Hz
Rated current A 11.3 11.5
Starting current A 15
Circuit breaker rating A 20
INDOOR
Fan type & quantity Crossflow x 1
Fan speeds H/M/L RPM 1350/1150/1000 1350/1200/1050
Air flow
(2)
H/M/L m3/hr 1250/1050/900 1250/1100/950
External static pressure Min-Max Pa N/A
Sound power level
(3)
H/M/L dB(A) 66/61/57
Sound pressure level
(4)
H/M/L dB(A) 51/48/44
Moisture removal l/hr 3
Condensate drain tube I.D mm 16
Dimensions WxHxD mm 1200x340x236
Weight kg 18.5
Package dimensions WxHxD mm 1305x430x325
Packaged weight kg 24
Units per pallet units 12 units per pallet
Stacking height units 6 levels
OUTDOOR
Refrigerant control EEV
Compressor type, model Twin Rotary DC Inverter Mitsubishi TNB220F
Fan type & quantity Propeller(direct) x 1
Fan speeds H/L RPM 850
Air flow H/L m3/hr 3600
Sound power level
(3)
H/L dB(A) 66
Sound pressure level
(4)
H/L dB(A) 56
Dimensions WxHxD mm 950x412x835
Weight kg 66
Package dimensions WxHxD mm 1080x477x910
Packaged weight kg 73.5
Units per pallet Units 2 units per pallet
Stacking height units 3 levels
Refrigerant type R410A
Refrigerant chargless distance kg/m 2.75/30
Additional charge per 1 meter g/m No need
Connections between units
Liquid line In.(mm) 3/8”(9.53)
Suction line In.(mm) 5/8”(15.88)
Max. tubing length m. Max.30
Max. height difference m. Max. 15
Operation control type Remote control
Heating elements kW
Others
(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN 14511.
(2) Airflow in ducted units; at nominal external static pressure.
(3) Sound power in ducted units is measured at air discharge.
(4) Sound pressure level measured at 1 meter distance from unit.
