14-4
EXPLODED VIEWS AND SPARE PARTS LISTS
SM FLODCI 2-A.4 GB
14.4 Outdoor Unit: GC 18 DCI
ItemNo. Part No. Description Qty
1 433218 Front panel A 1
2 4526340 Air inlet ring-420 1
3 433223 Painting insulation plate 1
4 4526476 Axial fan OD=401 1
5 4526475 DC motor for DCI 18 1
6 4526457 Motor support 1
7 4527363 Base painting Assy. 1
8 4526459 Partition 1
9 4526203 Outdoor DC inverter controller (English) 1
10 4524595 Gas valve (R410A) 1
11 4524176 Liquid valve (R410A) 1
12 4526224 EMI fliter board 901-098-00 1
13 4526396 Chock Assy. 167-021-01 1
14 4526223 AC-IN connected wire 1
14 4526968 Earthing wire for DCI 1
16 4526222 Fuse connecting wire 1
17 4526300 Therminal sheet 1
18 4526220 Fuse stand JEF-511B(EHK P/N:140-038-00) 1
19 4526533 Fuse 65TS(20A,230)140-031-00 1
20 204107 Cable clip nylon 1
21 4519188 4 poles terminal block 1
22 433229 Value cover 1
23 4522509 4-Way valve coil 1
24 4527327 4-way valve welding Assy. 1
25 4518952 4-way valve 1
26 4526221 Compressor wire 1
27 4523446 DC Inverter compressor Assy. 5CS130XCC03 1
28 4526775 Compressor top thermistor(CTT) 1
29 4526774 Outside air thermistor(OAT) 1
30 4526776 Outside coil thermistor(OCT) 1
31 4526969 Suction coil thermistor(SUCT) 1
32 4526214 Electronic expansion valve ZDPF(L)-1.6C-01-RK forR410A 1
33 4526216 EEV COIL QA(L)12-HR-01A-RK 1
34 4519606 Right side panel 1
35 433228 Back side net 1
36 4526459 Condenser soldering assy 1
37 4526298 Bridge 1
38 4519614 Painting top cover 1
39 4526480 Gasket for axial fan 1
40 4519300 Nut M5 L 1
41 433225 Handle 1
42 4519607 Left side panel painting plate 1
