9
b. Serrated Rubber Mounting
In sites where the spring isolators assemblies
cannot be installed, mount the unit as show in
Figure 6. Insert four 3/8” studs in the ceiling
according to the dimensions of the suspension
angle frame mounted on the unit. Prepare two
30x30 mm, 1.5 mm thick galvanized sheet metal for
each stud and assemble according to Figure 6. The
rubber pa may be substituted by springs suitable for
this type of installation.
1. Concrete Ceiling
2. Bolt for Ceiling Insert
3. Leveling Nut
4. Fastening Nut
Figure 6. Indoor Unit Installation -
Ceiling Mounting using Rubber
Isolators
5. OUTDOOR UNIT INSTALLATION
Installation on flat surface (roof, ground, etc.)
Install outdoor unit support in a position elevated at least
100 mm on a concrete pad, concrete block or wooden beams,
in order to allow free water flow underneath (See Figure 7).
1. Outside the building
2. Outdoor Unit
3. Serrated Rubber 40x80 mm
4. Floor
5. Concrete base or floor tiles
6. Anchor Screws
7. Wall
Figure 7. Outdoor Unit Installation Criteria
