CONTROL SYSTEM
Revision 0
12A.11 Horizontal swing – Horizontal louvers
• When the power is ON, the Horizontal Louver will reset to left
of A/C (0˚) and then stop.
• When the R/C signal of ON/OFF is received, the Horizontal
louver will run to last position.
• When Horizontal swing mode is received from R/C. it will rotate
to setting position.
Mode Left Motor Right Motor
10° 0°
222.5° 22.5°
345° 45°
4 67.5° 67.5°
590° 90°
60° 90°
7
0° 90
• The Horizontal louvers are driven by two step motor.
