12a-39
CONTROL SYSTEM
Revision 0
12A.21. Quick Run
Initiate the Quick Run Mode by using a R/C.
(i) Make sure that the correct A/C model has been selected by setting the jumpers J8, J3,
J4 and J5 (if available), and the correct group has been selected by setting the jumpers
J2 and J6. Jumper J1 must be disconnected.
(ii) Turn on the AC power to the unit and make sure that the unit is in operating mode.
(iii) Use a R/C to send the 1st setting to the ELCON unit
Heat/Fan Mode, High IFAN, SPT=16
o
c, no IFEEL, Sleep or any timer settings
(iv) Use a R/C to send the 2nd setting to the ELCON unit
Cool Mode, Auto IFAN, SPT=any, no IFEEL, Sleep or any timer settings.
(v) After the ELCON unit has received the two setting in the correct order, Quick Run Mode
will be started immediately.
(vi) This special R/C initiated Quick Run Mode can be exit by changing the unit setting from
Operating Mode to Stand-by Mode or resetting the unit.
Note: In (iii) and (iv), the 2nd setting must follow directly after the 1st setting. The timing is
not important. For example, sending the 2nd setting 1 hour after the 1st setting is still
acceptable. But if the two settings are separated by any other settings, such as Fan
Mode or Dry Mode, the Quick Run Mode will not be started.
After entering Quick Run mode, the unit will be speed up by 52 times. For example, the
compressor minimum off time will be speed up from 3 minutes to around 3 seconds; DI will
be speed up from 10 or 40 minutes to 12 or 46 seconds…
