Airwell HKD DCI Series User Manual

PRODUCT SPECIFICATION
Version - 2 10 HKD DCI
3.4 AWSI-HKD012-N11 / AWAU-YKD012-H11
Model Indoor Unit
AWSI-HKD024-N11
Model Outdoor Unit
AWAU-YKD024-H11
Installation Method of Pipe
Flared
Characteristics
Units
Cooling
Heating
Average
Warm
Cold
Capacity
(1)
kW
6.8(2.7-7.8)
7.5(1.6-8.7)
Pdesign
kW
6.8
5.5
6.7
7
SEER /SCOP
(2)
W/W
6.3
4
5.1
3.3
Energy efficiency class
A++
A+
A+++
B
Annual energy consumption
kWh
378
1925
1840
4455
Tbiv
o
C
N/A
-7
2
-15
Tol
o
C
N/A
-15
Power supply
V/Ph/Hz
220-240V/Single/50Hz
Circuit breaker rating
A
25
INDOOR
Fan type & quantity
Cross flow fan x1
Fan speeds
H/M/L/VL
RPM
1180 / 1100 / 900
Air flow
(3)
H/M/L/VL
m3/hr
960//890/820/650
External static pressure
Min-Max
Pa
0
Sound power level
(4)
H/M/L
dB(A)
63
Sound pressure level
(5)
H/M/L/VL
dB(A)
43/40/37/31
Moisture removal
l/hr
2.4
Condensate drain tube I.D
mm
16
Dimensions
WxHxD
mm
1045x315x235
Weight
kg
12
Package dimensions
LxWxH
mm
1135x315x395
Packaged weight
kg
15.2
Stacking height
units
7
OUTDOOR
Refrigerant control
EEV
Compressor type, model
Rotary DC Inverter
Fan type & quantity
Axial x 1
Fan speeds
H/L
RPM
810/750/600
Air flow
H/L
m3/hr
2700
Sound power level
(4)
H/L
dB(A)
68
Sound pressure level
(5)
H/L
dB(A)
59
Dimensions
WxHxD
mm
845x363x702
Weight
kg
48.4
Package dimensions
LxWxH
mm
965x395x755
Packaged weight
kg
51.6
Stacking height
Units
3
Refrigerant type
R410A
Refrigerant charge (standard connecting tubing length)
kg(5m)
2
Additional charge per 1 meter
gr / 1m
30
Connections between units
Liquid line
In.(mm)
3/8"
Suction line
In.(mm)
5/8"
Max.tubing length
m.
50
Max.height difference
m.
25
Operation control type
Remote control
Heating elements
kW
NA
Others
(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units).
(2) SEER / SCOP calculation accordance with EN14825.
