ELECTRONIC FUNCTION
Version - 2 38 HKD DCI
10. Electronic function
10.1 Abbreviation
T1: Indoor room temperature
T2: Coil temperature of evaporator
T3: Coil temperature of condenser
T4: Outdoor ambient temperature
T5: Compressor discharge temperature
10.2 Display function
10.2.1 Icon explanation on indoor display board.
1. In normal situation, the setting temperature is displayed.
(display room temp. in fan mode.)
2. Shows “SC” when self clean function is activated, ”FP” when 8ºC
heating function is activated.
3. Shows the alarm code whenever there is an alarm.
Lights up when ionizer or plasma function is activated.
Lights up when the unit is under defrosting operation or when the anti-cold
air function is activated.
Lights up when the unit is in operation.
Lights up when TIMER function is activated.
