EXPLODED VIEW AND SPARE PART LIST
HKD DCI 65 Version - 2
No.
BOM Code
Part Name
Quantity
1
12122000A01472
Panel assembly
1
2
12100204000673
Filter
2
3
17222000A00835
Structure Subassembly of Display Box
1
3.1
17122000A02292
VLED Display Module
1
4
12122000006694
E-Parts Cover Plate
1
5
12122000001883
frame assembly
1
5.1
12122000006272
Screw Cap
2
6
12100501000021
Drain Hose
1
7
15500406000016
Brass Nut
1
7
15500406000010
Brass Nut
1
8
12100303000008
Temperature Sensing Element Fixing clip
1
9
15822000000363
Evaporator assembly Gas valve assembly
1
10
12122000005431
Motor Bearing Cover
1
11
11002015000248
Brushless DC Motor
1
12
12122000000350
Bearing sleeve
1
13
12622000000006
Bearing pedestal
1
14
12100102000036
Cross-flow window rotor
1
15
12122000005105
Wind Guide Assembly
1
16
12122000004172
Chassis Assembly
1
16.1
11002010000143
stepper motor
1
17
12122000000445
Pipe Pressing Board
1
18
12222000000024
Installation Plate
1
19
17222000A18108
Electronic control box assembly
1
19.1
12122000007835
Electrical Control Box
1
19.2
12122000007840
Electrical Control Box
1
19.3
17122000019095
Indoor main control board assembly
1
19.4
11201007000221
Room Temperature Sensor
1
19.5
11201007000001
Temperature Sensor
1
19.6
17400401A00046
Wire holder
1
20
12122000004994
Electrical Control Box Cover
1
21
17317000A02580
Remote controller
1
22
12600701000039
Seal
1
23
12100509000061
Extend Water Pipe
1
24
12100204000685
Filter net of cold catalyst
1
53
12011600000015
Kit of Screw Accessories
1
