EXPLODED VIEW AND SPARE PART LIST
HKD DCI 71 Version - 2
No.
BOM Code
Part Name
Quantity
1
12122000A01256
Panel assembly
1
2
12100204000669
Air filter
1
3
12100204000658
Right side of the filter
1
4
17222000A00835
Structure Subassembly of Display Box
1
4.1
17122000A02292
VLED Display Module
1
5
12122000006693
E-Parts Cover Plate
1
6
12122000001910
frame assembly
1
6.1
12122000006272
Screw Cap
3
7
12122000006112
Wind Guide
1
8
12122000005591
Air Out Frame Assembly
1
8.1
11002010000015
stepper motor
1
9
12100501000021
Drain Hose
1
10
15500406000010
Brass Nut
1
10
15500406000003
Brass Nut
1
11
12100303000008
Temperature Sensing Element Fixing clip
1
12
15822000003687
Evaporator assembly Gas valve assembly
1
13
12122000005516
Motor Bearing Cover
1
14
12122000006772
Fixing board for motor
1
15
11002015000094
Brushless DC Motor
1
16
12122000000350
Bearing sleeve
1
17
12622000000006
Bearing pedestal
1
18
12100102000002
Cross-flow window rotor
1
19
12122000003943
Chassis Assembly
1
20
12222000000054
Pipe Pressing Board
1
21
12222000000008
Installation Plate Subassembly
1
22
17222000A18110
Electronic control box assembly
1
22.1
12122000004598
Electrical Control Box
1
22.2
17122000018901
Indoor main control board assembly
1
22.4
11201007000003
Room Temperature Sensor
1
22.5
11201007000126
Temperature Sensor
1
22.6
17400401000032
Wire holder
1
23
12122000005046
Electrical Control Box Cover
1
24
17317000A02580
Remote controller
1
25
12600701000039
Seal
1
26
12100509000061
Extend Water Pipe
1
27
12100204000685
Filter net of cold catalyst
