Airwell HKD DCI Series User Manual

EXPLODED VIEW AND SPARE PART LIST
HKD DCI 73 Version - 2
No.
BOM Code
Part Name
Quantity
1
11201007000039
Room Temperature Sensor
1
2
15822000003296
Condenser Assembly
1
3
11201007000136
Temperature Sensor
1
4
12222000003597
Parts fn Right Side Plate
1
5
12100701000015
Big Handle.
1
6
12122000007150
Water Collecting Cover
1
7
12222000004427
Chassis assembly
1
8
12222000004424
Front panel
1
8.1
12122000A03621
Air outlet grille
1
10
12100105000057
Axial fan
1
11
11002015000041
Brushless DC Motor
1
12
12222000004187
Supporter assembly of fan motor
1
13
12222000001232
Left Side Floor
1
14
12222000003598
Top cover assembly
1
15
12222000004425
Partition board assembly
1
17
15422000004672
4-Ways valve assembly
1
17.1
15500204000021
Low Pressure Valve
1
17.2
15500216000028
4-way Valve
1
17.3
12222000002571
Installing plate for valves
1
18
15422000004758
Liquid valve assembly
1
18.1
15500208000028
Liquid valve
1
19
11103020000034
Inverter Controlled Rotary Compressor
1
20
11201007000005
Discharge temperature sensor assembly
1
21
17222000A17890
Electronic control box assembly
1
21.1
12222000001455
Electric Installing Box Cover
1
21.2
17122000018543
Outdoor power board assembly
1
21.3
12122000006913
Installation board for E-parts
1
21.5
12222000001311
Electric Installing Box Subassembly
1
22
15500406000010
Brass Nut
1
22
15500406000016
Brass Nut
1
