Airwell HKD DCI Series User Manual

EXPLODED VIEW AND SPARE PART LIST
HKD DCI 79 Version - 2
No.
BOM Code
Part Name
Quantity
1
12222000004782
Terminal board
1
2
12122000007150
Water Collecting Cover
1
3
15422000004833
4-way valve assembly
1
3.1
15500204000025
Low Pressure Valve
1
3.2
15500216000026
4-way Valve
1
4
12122000A03617
Air outlet grille
1
5
17222000A17928
Electronic control box assembly
1
5.2
12222000004827
Cover of electronic control box
1
5.3
17122000018903
Outdoor main control board assembly
1
5.4
12122000006856
Electric Installing Box Subassembly
1
6
12100701000015
Big Handle.
1
7
12222000004884
Supporter assembly of fan motor
1
8
11002015000397
Brushless DC Motor
1
9
12222000004794
Left side plate assembly
1
11
11103020000179
Inverter Controlled Rotary Compressor
1
12
12222000004795
Top cover assembly
1
13
15500406000003
Brass Nut
1
13
15500406000010
Brass Nut
1
14
12222000004784
Partition board assembly
1
15
15822000004516
Condenser Assembly
1
16
11201007000039
Room Temperature Sensor
1
17
12222000004823
Chassis assembly
1
17.1
12222000004786
Chassis
1
17.2
12222000004788
Footing
2
18
17400401000016
Wire holder
1
19
15422000004974
Liquid valve assembly
1
19.1
15500208000023
Liquid valve
1
19.2
12222000002571
Installing plate for valves
1
20
12222000004822
Front panel
1
21
12222000004785
Right side plate
1
23
11201007000069
Temperature Sensor
1
24
12100105000181
Axial fan
1
25
17400306000058
Reactor
1
26
11201007000005
Discharge temperature sensor assembly
1
