7. ELECTRICAL DATA
7.1 Single Phase Unit
Model PNX009 DCI PNX012 DCI
Power Supply 1 PH ,220-240VAC ,50HZ
Connected to To indoor
Maximum Current 10A
Inrush Current \
(a)
35A
Starting Current\
(b)
10A
Circuit Breaker 16A
Power Supply wiring no. x cross section 3 X 1.5 mm²
Interconnecting cable no. x cross section 4 X 1.5 mm²
(a) Inrush current is the current when power is up (charging the DC capacitors
at outdoor unit controller).
(b) Starting current is the current at compressor start up.
NOTE
Power wiring cord should comply with local lows and electrical
regulations requirements.
