2-1
PRODUCT DATA SHEET
SM PNXDCI 1-A.1 GB
2. PRODUCT DATA SHEET
2.1 PNX009 / GC 9 DCI Nordic
Model PNX009 DCI / GC 9 DCI Nordic
Item Cooling Heating
Capacity
Btu/hr 8530 (3750-122800) 11600 (5290-17060)
Kcal/hr 2150(950-3100) 2920(1330-4300)
W 2500 (1100-3600) 3400 (1550-5000)
Total Input (Cooling / Heating) W 600 (350-1000) 830 (350-1500)
E.E.R(Cooling) / C.O.P(Heating) W/W 4.10 4.05
Running Current(Cooling/Heating) A 2.7 3.7
Starting Current A 10.50
Power Supply (ph, cy, voltage) single phase 50HZ 220-240V
Dehumidification L/h 1.0
INDOOR UNIT
External finish High Polish
Ionizer Yes(Optional)
Electrostatic Filter dB(A) Yes(Optional)
Heat exchanger Hydrophilic louver fin coil
Fan (drive) Crossflow * 1
Fan motor output W 20
Airflow (Hi-Me-Lo) m 3/hr 530-430-330 570-460-350
Operation control type Remote control
Noise level(Lo-Hi)
Pressure
(4)
dB(A)
26-38 26-39
Power 39-50 39-51
Condensate drain I.D. mm(in) 16(5/8)
Dimensions W*D*H 810*202*285
Weight kg 11
Packing dimensions W*D*H mm 885*285*360
Unit stacking units 7
OUTDOOR UNIT
Refrigerant control Electronic Expansion Valve
Compressor type Scroll DC Inverter
Compressor Model Matsushita 5CS102XDA04
Starter type ---
Protection device Outdoor SW control
Heat exchanger Hydrophilic louver fin
Fan (drive)* No. Propeller * 1
Motor output W 50
Airflow m3/h 1780
Defrost method Reverse cycle
Noise level
Pressure
(4)
dB(A)
49 49
Power 59 59
Dimensions W*D*H mm 795*290*610
Weight kg. 38
Packing dimensions W*D*H mm. 945*395*655
Unit stacking units 3
TUBING
Refrigerant R410A
Charge(20m connection tube) g 1100
Fresh Air No
Tube size O.D.
liquid mm(in) 6.35
suction mm(in) 9.53
Connection method
between the indoor
and outdoor unit
indoor & outdoor Flared
height difference m Max. 10m
tubing length m Max. 20m
additonal charge No need
(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN 14511.
(2) Airflow in ducted units; at nominal external static pressure.
(3) Sound power in ducted units is measured at air discharge.
(4) Sound pressure level measured at 1 meter distance from unit.
