Engineering manual
90
2.1 Specification
Model name 021 024 030 036
Power source 220-240V，1phase,50/60Hz
KW 6.3 7.1 9 11
Cooling capacity
KBTU/h 21.5 24.23 30.71 37.53
KW 7 8 10 12.5
Heating capacity
BTU/h 23.88 27.3 34.12 42.65
Cooling kW 0.049 0.054 0.094 0.133
Power input
Heating kW 0.049 0.054 0.096 0.136
Cooling A 0.4 0.5 0.8 1.1
Running
amperes
Heating A 0.4 0.5 0.8 1.1
Type Turbo fan×1
Airflow fate m3/h 1080/980/880 1140/1000/910 1490/1370/1250 1650/1510/1360
Fan motor
Output kW 0.07 0.15
Operating sound(H/M/L) dB(A) 46/43/41 46/44/42 49/47/45 53/50/47
Unit mm 840×840×230 840×840×300
Dimensions
(W×D×H)
Frame mm 950×950×30
Liquid(Flare) mm 9.53
Gas(Flare) mm 15.88
Tubing
connections
Drain piping mm 32(16mm also can be linked through the connector)
Net weight kg 24/5.5 29/5.5
The operating sound pressure value is tested 1m away from the unit.
The test temperature conditions
Cooling: Indoor/outdoor(27/19//35/24)
Heating: Indoor/outdoor(20/15//7/6)
