- 06 -
2.3 Preparation
2.4 Installation
Before installation, please find in the standard accessories a set of 2 hexagon wrenches. Please retain this tool kit, it is useful for
maintenance and transportation of the unit. As metric standard tools, you may find replacement at home or in a hardware store.
A pair of work gloves is recommended to protect your hands from dirt and scratches.
1. Take out the scooter stem and put down the kick stand (see 5.3) to fix the scooter body. Insert the connector below the stem into the
15-pin plug, then fix them with 5 M6*20 screws and the hexagon wrench. (see I-1)
2. Fix the front and rear supporting plates of the saddle with 2 M6*20 screws. (see I-2)
3. Fix the saddle on the scooter body with 6 M6 screws. (see I-3)
I-1 I-2 I-3
