! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-17-
ELECTRICAL PARTS LIST -11/12 (AZM-6) -1/1
AZM-6
YR3NC
DECK O CN 1 87-A61-731-010 CONN,07P H 621600711 a
DECK O CRD1 8A-ZM6-603-010 RBN,CORD,2P-75 a
DECK S IC 1 87-020-454-010 IC,DN6851 a
DECK O SW 1 87-036-109-010 SW,MICRO SPPB61 a
DECK O SW 2 87-036-109-010 SW,MICRO SPPB61 a
DECK O SW 3 87-036-109-010 SW,MICRO SPPB61 a
