! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-6-
ACCESSORIES PARTS LIST -1/1
CSD-TD49 CSD-TD49 CSD-TD49 CSD-TD49 CSD-TD49 CSD-TD49
ULC UWC LHLC LHSC LHWC UCWC
! X AS1001 87-A80-109-010 AC CORD,HK7281 BLK U a b . . . f
! O AS1002 87-A80-187-010 AC CORD SET ASSY,BRAZ BLK . . c d e .
! O AS1003 87-A91-017-010 PLUG,CONVERSION JT-0476 . . c d e .
O AS1004 8C-CHM-951-010 RC UNIT,RC-CAT2 a b c d e f
O AS1005 8C-CHB-903-010 IB,U/C(ESF)AL TD39/49 a b . . . f
O AS1006 8C-CHM-902-010 IB,LH(ESP)AL TD49 . . c d e .
To Next Page
