Aiwa TP-IC10 D - Mechanical Main Parts List 1;1

15
REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.
MECHANICAL MAIN PARTS LIST 1/1
Basic color symbol Color Basic color symbol Color Basic color symbol Color
B Black C Cream D Orange
G Green H Gray L Blue
LT Transparent Blue N Gold P Pink
R Red S Silver ST Titan Silver
T Brown V Violet W White
WT Transparent White Y Yellow YT Transparent Yellow
LM Metallic Blue LL Light Blue GT Transparent Green
LD Dark Blue DT Transparent Orange
COLOR NAME TABLE
1 8Z-HT5-004-010 -- GRILLE,SPEAKER
2 8Z-HT5-003-010 -- RING,SPEAKER
3 87-A91-158-110 2A SPKR,DIA 50 4OHM 1.0W K050NA50
4 8Z-HT5-005-010 1A WINDOW,CASS
5 8Z-HT5-015-010 1C LID,CASS D
6 8Z-HT5-010-010 0E LENS,BATT/LL INDI
7 8Z-HT5-007-010 1B GRILLE,MIC
8 8Z-HT5-006-010 1A PANEL,MIC
9 8Z-HT5-201-010 0E HLDR,MIC
10 82-TP3-609-010 1C ECM
11 8Z-HT5-009-010 -- LENS,LL INDI
12 8Z-HT5-023-010 -- CAP,LL BTN REC D
13 8Z-HT5-202-010 -- BASE,LL BTN
14 87-HT8-203-010 -- SPR-P,CASS
15 87-HT8-208-010 -- SPR-T,LID CASS
16 8Z-HT5-017-010 -- FRAME,CENTER D
17 87-040-196-010 1H COUNTER
18 87-HT8-202-010 0E HLDR,COUNTER
19 8Z-HT5-025-010 -- CAP,LL BTN REC/PLAY
20 87-HT8-205-010 -- LEVER,REC SAFETY
21 8Z-HT6-010-010 0E BTN,PLAY
22 8Z-HT6-012-010 0E BTN,FF
23 8Z-HT6-013-010 0E BTN,REW
24 8Z-HT6-014-010 0E BTN,STOP
25 8Z-HT6-011-010 0E BTN,REC
26 8Z-HT7-203-010 0E LEVER,PAUSE
27 8Z-HT4-201-010 -- BAT-CONTACT,(-)
28 8Z-HT7-205-010 0E BAT-CONTACT,(+)
29 8Z-HT7-007-010 0E LID,BATT
30 8Z-HT5-016-010 1C CABI,REAR D
31 8Z-HT5-012-010 0E KNOB,SL LL 45/10
32 8Z-HT5-011-010 0E KNOB,SL LL ON/OFF
33 8Z-HT7-012-010 0E FOOT,RUBBER
34 8Z-HT7-008-010 0E KNOB,SL PAUSE
35 8Z-HT5-013-010 0E KNOB,SL NFR/V
36 87-HT8-210-010 -- BELT,COUNTER
37 87-HT8-209-010 -- SPR-E,REC SAFETY
38 8Z-HT5-024-010 -- CAP,LL BTN PLAY D
A 87-HT8-211-010 0E VT2+2-18 S-SCREW BLK
B 87-067-769-010 0E VT2+1.7-8(3) BLK
C 87-067-271-010 0E SCREW VFT2+1.7-4
D 87-354-529-310 0E VT2+1.7-4
E 87-351-508-310 -- VT2+1.4-3.5 BLK
