17
REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.
TAPE MECHANISM PARTS LIST 1/1
1 S1-909-013-040 -- CHASSIS ASSY
2 S1-909-020-190 0E FR PLATE
3 S1-909-020-090 0E LOCK PLATE
4 S1-909-020-140 OE STOP SPRING
5 S1-909-120-030 -- REC LEVER SPRING
6 S1-909-120-070 1C REC LEVER
7 S1-909-120-020 1A MG GUIDE
8 S6-207-100-020 1B HEAD E TC-230AN(SL)
9 S1-852-140-020 0E M LUBBER
10 S1-909-030-050 1C HEAD PANEL
11 S1-909-040-020 -- P/R SPRING
12 S1-909-030-080 0E R/C SPRING
13 S1-909-030-070 0E R/C PLATE
14 S1-909-030-060 1B TAPE GUIDE
15 S1-852-140-030 0E M COLLOR
16 S1-944-030-020 0E HEAD SPRING PLATE
17 S6-202-030-410 -- RP HEAD MS15R-BA2N1
18 S1-909-020-100 0E STOP LEVER
19 S1-909-110-040 0E AUTO LEVER
20 S1-909-110-020 0E A PUSH ARM
21 S1-909-110-050 0E M CONTROL SPRING
22 S1-909-060-150 -- SENSOR SPRING C
23 S1-909-063-030 1D T REEL ASSY
24 S1-909-060-130 0E TAKE UP GEAR
25 S1-909-030-090 0E HP SPRING
26 S1-909-083-050 -- MOTOR ASSY
27 S1-909-050-130 1A BRAKE BELT
28 S1-909-043-020 -- PINCH ROLLER ASSY
29 S1-909-020-200 0E FR PLATE SPRING
30 S1-909-020-120 0E FF LEVER
31 S1-909-053-040 1D FLYWHEEL ASSY
32 S1-909-080-100 1A MAIN BELT
33 S1-909-050-100 1B FL BRACKET
34 S1-909-020-150 0E R/C LEVER(R)
35 S1-909-020-160 0E R/C LEVER(F)
36 S1-909-060-120 1A CAM GEAR
37 S1-909-020-170 1A R/C BRACKET
38 S1-909-020-110 1A RWD LEVER
39 S1-909-020-180 0E FF STOPPER
40 S6-401-011-630 1B LEAF SW MSW-1541TA
41 S1-909-077-010 -- RWD GEAR
42 S1-909-020-130 0E FR SPRING
43 S1-909-120-090 -- REC SPRING PLATE
44 S1-909-120-100 -- REC SW LEVER
A S9-C01-174-030 0E CAMERA 1.7-4
B S9-C01-173-530 0E CAMERA 1.7-3.5
C S9-P14-203-310 0E +/- SCREW M2-3.3
D S9-C18-300-100 0E CAMERA 1.7-3
E S9-P08-173-410 0E PST 1.7-3.4
F S9-P14-206-320 0E +/- SCREW M2-3.6
G S9-W02-300-100 0E P WASHER CUT 1.2-3.8-0.3
H S9-W08-350-200 0E LUMILER WASHER CUT 0.98-3-0.3
I S9-W05-200-600 0E HL WASHER 1.16-3-0.2
J S9-W05-200-100 0E HL WASHER 1.55-3-0.13
K S9-C16-171-410 -- CAMERA 1.7-1.4
