AJ 40486 - Parts List

3 | 01252 359760 • ajproducts.co.uk
6. PARTS LIST
No. Description Qty.
1 Handle Grip 1
2 Pin 1
3 Upper Handle 1
4 Lower Handle 1
5 Socket 1
6 Pin 6
7 Pin 3
8 Linkage 1
9 Pump Plunger 1
10 Back-Up Ring 1
11 O-Ring 1
12 Y-Ring 1
13 Pump Cylinder 1
14 Washer 1
15 Ball 3
16 Pin 1
17 Release Pin 1
18 Square Ring 1
19 Screw 1
20 O-Ring 1
21 Screw 1
22 Ball Seat 1
23 Ball 1
24 Snap Ring 1
25 Valve Base 1
26 Ball 2
53 Pin 1
54 Screw 1
27 Screw 2
28 Filter 1
29 O-Ring 1
30 T-Ring 1
31 O-Ring 1
32 Retaining Ring 1
33 Piston 1
34 Piston Rod 1
35 Cylinder 1
36 Oil Plug 1
37 Oil Tank 1
38 Square Ring 1
39 Cylinder Head 1
40 O-Ring 1
41 Regulating Screw 1
42 Saddle 1
43 Snap ring 1
44 Toe Yoke 1
45 Toe Mount 1
46 Hanging Ring 1
47 Screw 1
48 Nut 1
49 Axle 1
50 Axle Bush 1
51 Wheel 1
52 Nut 1
55 Yoke 1
56 Jack 1
