AJA GEN10 HD/SD Sync Generator User Manual — Specifications
Specifications
Item Specification
HD Sync Tri-level
SD Sync Color Black, 75% Color Bars
AES-11 Output AES-11, 48KHz, Silent or 1KHz Tone (-20dBFS for NTSC,
-18dBFS for PAL), 1 BNC
Video Sync Outputs Assignable in two groups to either HD or SD:
4 BNCs—Outputs 1 to 4
2 BNCs—Outputs 5 and 6
Accuracy 3 ppm
Formats 525i, 625i
720p23.98/24/25/29.97/30/50/59.94/60
1080i50/59.94/60
1080psF23.98/24/25/29.97/30
1080p23.98/24/25/29.97/30
User Controls External Dipswitch
Size 5.8" x 3.1" x 1 (147 x 79 x 25mm)
Power 5-18VDC, 2 watts. Requires power supply.
