AJAX Fire Protect User Manual

Rapid temperature rise
The state of rapid temperature increase alarm
High CO Level (Fire Protect
Plus only)
The state of dangerous CO level alarm
Backup Battery Charge
Backup battery level of the device
Smoke sensor
The state of the smoke detector
Smoke sensor dust level
The dust level in the smoke chamber
Firmware
Detector firmware version
Device ID
Device identifier
Setting
1. Devices
2. Fire Protect | Fire Protect Plus
3. Settings

AJAX Fire Protect Specifications

General

Smoke-sensitive element	Photoelectric sensor
Temperature sensitive element	Thermocouple
Tamper protection	Yes
Compatibility	Operates independently or with Hub, Hub Plus, Hub 2, ReX, ocBridge Plus, uartBridge
Sound notification volume	85 dB at a distance of 3 m
Alarm threshold at the temperature	+59°С ±2°С
Operating temperature range	From 0°С to +65°С
Operating humidity	Up to 80%
Frequency band	868.0 – 868.6 MHz or 868.7 – 869.2 MHz depending on the region of sale
Radio signal modulation	GFSK
Radio signal range	Up to 1, 300 m (any obstacles absent)
Maximum RF output power	Up to 20 mW
Power supply	2 × CR2 (main batteries), CR2032 (backup battery), 3 V
Battery life	Up to 4 years

Weight and Dimensions

Overall dimensions	132 × 132 × 31 mm
Weight	220 g
