AJAX Fire Protect User Manual

States
1. Devices
2. FireProtect | FireProtect Plus
Parameter
State
Temperature
Temperature of the device. Measures on the device processor
and changes gradually
Jeweller Signal Strength
Signal strength between the hub and the detector
Connection
Connection status between the hub and the device
Battery Charge
Primary battery level of the device
Lid
The tamper state of the device — reacts to the detachment
Routed Through ReX
Displays the status of using the ReX range extender
Smoke
Shows if smoke is detected
Temperature threshold exceeded
The state of temperature threshold exceeded alarm

AJAX Fire Protect Specifications

General

Smoke-sensitive element	Photoelectric sensor
Temperature sensitive element	Thermocouple
Tamper protection	Yes
Compatibility	Operates independently or with Hub, Hub Plus, Hub 2, ReX, ocBridge Plus, uartBridge
Sound notification volume	85 dB at a distance of 3 m
Alarm threshold at the temperature	+59°С ±2°С
Operating temperature range	From 0°С to +65°С
Operating humidity	Up to 80%
Frequency band	868.0 – 868.6 MHz or 868.7 – 869.2 MHz depending on the region of sale
Radio signal modulation	GFSK
Radio signal range	Up to 1, 300 m (any obstacles absent)
Maximum RF output power	Up to 20 mW
Power supply	2 × CR2 (main batteries), CR2032 (backup battery), 3 V
Battery life	Up to 4 years

Weight and Dimensions

Overall dimensions	132 × 132 × 31 mm
Weight	220 g
