AJAX FireProtect 2 User Manual

After starting the test, the red LED of the detector ashes 5 times in a row. The
detector’s siren beeps in time with an LED indication. When the test is over,
users receive a notication of the detector state in Ajax apps.
The detector also noties of the test result with sound and LED indications. If
the test is failed and a malfunction is detected, 3 seconds after the start of the
test, the detector starts the indication Malfunction detected: the yellow LED
ashes twice, the siren beeps two times in time with the LED indication.
The self-test does not start immediately, but no later than 30 seconds after pressing the
Test/Mute button or running from the Ajax app.
To stop a self-test, press the Test/Mute button again.
If there were no sound and LED indications during the self-test, the detector cannot be
used. Contact our .
Testing at the place of installation
Ajax system provides several tests to select the correct installation place of
devices. Jeweller Signal Strength Test is available for FireProtect 2. The test
determines the strength and stability of the signal at the intended location of the
device.
To run the test in the Ajax app:
2. Select the hub if you have several of them or if you are using the
.
Ajax PRO
app
3. Go to the Devices menu.
4. Select FireProtect 2 (Heat/Smoke).
5. Go to the settings by clicking on the gear icon .
6. Click on the Device Self-testeld.
Technical Support
1. Select the hub if you have several of them or if you are using the
.
Ajax PRO
app

AJAX FireProtect 2 Specifications

General

Brand	AJAX
Model	FireProtect 2
Category	Security System
Language	English
