USB playback
Trouble Action
No playback USB device is not installed or installed incorrectly. Insert USB
device into slot.
Incompatible USB device used. Playback using any USB device
cannot be guaranteed. Please try another USB device.
Technical data8.
Parameter Value
Voltage 12 V
DC
Voltage tolerance 10.8 - 15.6 V
DC
Power consumption 10 A
Standby power consumption < 10 mA
Max power output 40 W x 4
Speaker impedance 4/8 Ω
USB connection USB 2.0 compatible
Flash memory connection SD/MMC
Dimensions (W x H x D) 177 x 50 x 200 mm
Weight 1.356 kg
Tuner
Parameter Value
Frequency range 87.5 - 108 mHz
Sensitivity 2.8 miniV
Stereo Separation 30 dB
Signal/Noise Ratio 50 dB
Channel step 50 kHz
Intermediate frequency 10.7 mHz
Disc output
Parameter Value
Frequency response 20 Hz - 20 kHz
Channel separation > 50 dB (1 kHz)
