USB playback
Trouble Action
No playback USB device is not installed or installed incorrectly.
Insert USB device into slot.
Incompatible USB device used. Playback using any
USB device cannot be guaranteed. Please try
another USB device.
AUX
Trouble Action
No sound on the unit system Input source is low. Increase the volume level on the
audio source device.
No picture Check if the TV is switched on and set to the correct
A/V input.
Check cables for connection problems.
Check cables for damage.
Remote control (RC)
Trouble Action
RC does not function Check the battery installation.
Point the RC at the remote control sensor.
Stay within 8 metres of the appliance.
Technical data8.
Parameter Value
Voltage 100 ~ 240V
AC
/ 50 ~ 60 Hz
Power consumption ≤ 50 W
Standby power consumption ≤ 1 W
Max power output 2 x 126 W
Headphones output impedance 32 Ω
USB connection USB 2.0 compatible
Dimensions (W x H x D) 160 x 153 x 264 mm
Weight 2.8 kg
