Akai MPK225

Comment Description Designator Footprin t LibRef Quantity
1_56_0106
C1, C3, C6, C19, C20,
C75, C76, C77, C78, C79
C1206 1_56_0106 10
1_62_0104
C5, C7, C8, C15, C16,
C17, C18, C21, C23,
C24, C25, C26, C27,
C28, C29, C30, C31,
C32, C33, C34, C35,
C36, C37, C38, C39,
C40, C41, C43, C44,
C45, C66, C67, C69,
C71, C72, C73, C90,
C93, C95, C1000,
C1001, C1002, C1003,
C1004, C1005, C1006,
C1007, C1008, C1009,
C1010, C1011, C1012,
C1013, C1014, C1015,
C1016, C1017
C0603 1_62_0104 57
22uF,16V 22uF,16V C22 EC4.0*4.3-B 1_08_0222 1
1_56_0102 C63, C65 C0603 1_56_0102 2
1_62_0103 C89, C92, C94 C0603 1_62_0103 3
1_61_0102 C91 C0603 1_61_0102 1
BAV99 BAV99 D3 SOT-23-1 2_50_00 99 1
SMAJ10A SMAJ10A D21 MLL35S-2 2_52_0002 1
DC11B2421403-(YN) DC11B2421403-(YN) E1 SWDC11B20214A8 6_00_0013 1
FCN1T1001602
BO T TOUCH 16P 1.0mm
SMD Lock
J2, J4 FCN1T1001602 FCN1T1001602 2
4_15_1406 J3 FCN1T1001402 4_15_1406 1
TE612000301 CN3P20V J6, J7 DCN3P20V TE612000301 2
4_15_0200 J13 DCN2P20H 4_15_0200 1
4_15_0608 J15 DTE6P20V-02 4_15_0608 1
4_15_3000 J17 FCN1T1003001 4_15_3000 1
4_15_2604 J18 FCN1T1002602 4_15_2604 1
4_14_0016 J19 DCN16P20H 4_14_0016 1
1K @ 100MHz
BEAD 1000 OH MS @
100MHZ 100mA 0603
L7 L0603 7_20_0080 1
AMBER
LED1, LED2, LED3,
LED4, LED5, LED6,
LED7, LED8, LED9,
LED10, LED11, LED12,
LED13, LED14, LED15,
LED16, LED17, LED18,
LED19, LED20
LED0603 RE_3_20_0037 20
Red Red/0603 LED21 LED0603 LDKPT-1608SURCK 1
Gre en Green/0603 LED22 LED0603 LDKPT-1608CGCK 1
MBT4403 MBT4403 Q 1, Q10, Q12, Q13 SO T23-C 2_51_4403 4
MBT4401 MBT4401 Q 11, Q14 SOT23-C 2 _51_4401 2
0_12_0470
R1, R5, R7, R76, R77,
R451, R452
R0603 0_12_0470 7
10K 10K R3, R4, R35, R64 AL0-17-8103 0_17_8103 4
0_09_0044
R8, R9, R12, R22, R32,
R44, R65, R91
DRV 112F-40B1-LF 0_09_00 44 8
0_12_0103 R10, R244, R246 R0603 0_12_0103 3
0_15_0000 R11, R13, R247, R248 R0603 0_15_0000 4
0_15_0000-DNS R33 , R94, R97, R105 R0603 0_15_0000-DNS 4
0_17_0470
R204, R205, R206,
R207, R208, R209
4R0603-1 0_17_0470 6
0_15_0103
R234, R237, R238,
R239, R240
R0603 0_15_0103 5
0_16_1509 R235 R0603 0_16_1509 1
0_15_0471 R236 R0603 0_15_0471 1
0_15_0681 R241, R1001 R0603 0_15_0681 2
0_16_4751 R243 R0603 0_16_4751 1
0_15_0100 R1000 R0603 0_15_0100 1
PRESET SW 0 SWEVQ11L04M MJS_6_02_0075 1
EDIT SW 1 SW EVQ11L04M MJS_6_02_007 5 1
GLOBAL SW 2 SWEVQ 11L04M MJS_6_02_0075 1
PROGRAM CHANGE SW 3 SWEVQ 11L04M MJS_6_02_0075 1
LEFT SW4 SWEVQ11L04M MJS_6_02_0075 1
RIGHT SW5 SWEVQ11L04M MJS_6_02_0075 1
UP SW 6 SWEVQ 11L04M MJS_6_02_0075 1
DOWN SW7 SWEVQ 11L04M MJS_6_02_0075 1
A SW 8 SWEVQ 11L04M MJS_6_02_0075 1
B SW9 SWEVQ11L04M MJS_6_02_0075 1
C SW10 SW EVQ11L04M MJS_6_02_0075 1
D SW11 SWEVQ11L04M MJS_6_02_0075 1
FULL LEVEL SW 12 SWEVQ11L04M MJS_6_02_0075 1
OCTAVE DOW N SW13 SWEVQ11L04 M MJS_6_02_0075 1
OCTAVE UP SW 14 SWEVQ11L04M MJS_6_02_0075 1
PREVIEW SW15 SW EVQ11L04M MJS_6_02_0075 1
NOTE REPEAT SW16 SWEVQ11L04M MJS_6_02_0075 1
ARP SW17 SWEVQ11L0 4M MJS_6_02_0075 1
LATCH SW 18 SWEVQ11L04M MJS_6_02_0075 1
LOOP SW19 SW EVQ 11L04M MJS_6_02_0075 1
TAP TEMPO SW20 SW E VQ11L04M MJS_6_02_0075 1
CONTROL BANK A SW 21 SWEVQ11L04M MJS_6_02_0075 1
TIME DIVISION SW 22 SWEVQ11L04M MJS_6_02_0075 1
REW IND SW 23 SWEVQ11L04M MJS_6_02_0075 1
FFWD SW24 SWEVQ11L04M MJS_6_02_0075 1
STOP SW25 SWEVQ 11L04M MJS_6_02_0075 1
PLAY SW26 SWEVQ11L04M MJS_6_ 02_0075 1
RECORD SW 27 SWEVQ11L04M MJS_6_02_0075 1
SOF TKEY 1 SW28 SWEVQ11L04M MJS_6_02_0075 1
SOF TKEY 2 SW29 SWEVQ11L04M MJS_6_02_0075 1
SOF TKEY 3 SW30 SWEVQ11L04M MJS_6_02_0075 1
SOF TKEY 4 SW31 SWEVQ11L04M MJS_6_02_0075 1
TESTPIN
TP1, TP4, TP6, TP9, TP10,
TP14, TP15
TEST PIN TESTPIN 7
SMD_TESTPIN TP2, TP3, TP5, TP7 DICT-TEST SMD_TESTPIN 4
74HC165 74HC165 U1, U2, U3, U4 CSSO P16P.65-180 2_64_1165 4
74HC4051 74HC4051 U9, U10 SOP16P150 2_73_4051 2
74AHC04 74AHC04 U22 SOP14P150 2_62_0004 1
74HC595 74HC595 U62, U63, U64 SOP16P150 2_64_0595 3
5KB 5KB VR1, VR2 VRR50202901 VRR50202901 2
