Akai MX-550 - Page 12

Ref.No. Part No.
TR760 ET-353899
TR761 ET-353899
TR801 ET-354371
TR802 ET-354371
TR803 ET-354371
TR804 ET-354371
TR805 ET-354371
TR806 ET-353897
TR807 ET-354371
TR808 ET-354370
TR809 ET-373392
TR810 ET-369248
TR811 ET-353897
TR812 ET-354370
TR815 ET-353899
TR816 ET-354371
TR817 ET-356336
TR818 ET-401091J
TR819 ET-401091J
TS801 ES-362883
wi EW-408676J
we EW-408679J
W3 EW-408681J
X801 El-405327J
X802 El-368825M
Description
TR 28A1317 §,T,U
TR 2SA1317 S,T,U
TR DTC124ES
TR DTC124ES
TR DTC124ES
TR DTC124ES
TR DTC124ES
TR DTC114ES
TR DTC124ES
TR DTA124ES
TR DTC124XS
TR DTA114YS
TR DTC114ES
TR DTA124ES
TR 2SA1317 S,T,U
TR DTC124ES
TR DTA114ES
TR 28D2144S U,V.W TO5
TR 2802144S U,V,W T05
SW TACT SKHHLM
WIRE ASSY HFG07157601 L580 15P
_ WIRE ASSY 52305-1411 L=650 14P
WIRE ASSY HFG0711-5201L530 11P
OSC CE CST6.00MGW 6.000MHZ
OSC X’TAL C-002RX 32.768KHZ
5. FLD/TONE P.C BOARD (TP-550)
Ref.No. Part No.
D1 ED-307572
De ED-307572
D3 ED-307572
D4 ED-307572
DS ED-307572
D6 ED-307572
D7 ED-408651J
DS ED-408651J
D9 ED-408651J
D10 ED-307572
IC1 El-400756J
IC2 El-400756J
IN1 EM-408409J
PH1 ET-403246J
TR1 ET-353899
TS1 ES-408641J
TS2 ES-408641J
TS3 ES-408641J
TS4 ES-408641J
TS5 ES-408641J
TS6 ES-408641J
TS7 ES-408641J
TS8 ES-408641J
TS9 ES-408641J
TS10 ES-408641J
VR1 EV-408642J
vVR2 EV-408643J
we EW-408817J
W3 EW-408817J
w4 EW-408816J
Description
D SILICON H 18S$131
D SILICON H 188131
D SILICON H 18S131
D SILICON H 18$131
D SILICON H 188131
D SILICON H 1SS131
D LED SEL2913K ORANGE
D LED SEL2913K ORANGE
D LED SEL2913K ORANGE
D SILICON H 1SS131
IC NJM4558L-B
IC NJM4558L-B
IND FL 10-MT-44GK CHARACTER
DETECTOR HC-377
TR 2SA1317 S,T.U
SW TACT EVQ 233 07K TO5
SW TACT EVQ 233 07K T05
SW TACT EVQ 233 07K TO5
SW TACT EVQ 233 07K TO5
SW TACT EVQ 233 07K TOS
SW TACT EVQ 233 07K TOS
SW TACT EVQ 233 07K T05
SW TACT EVQ 233 07K TO5
SW TACT EVQ 233 07K TOS
SW TACT EVQ 233 07K TOS
VR ROTARY RK14K1240L=20 B103X2
VR ROTARY RK14K1240L=15 B103X2
CORD A6007 L=160 13P
CORD A6007 L=160 13P
CORD A6007 L=160 9P
6. FLD P.C BOARD (TP-650)
Ref.No.
D101
D102
D103
0104
D105
D106
D107
D108
D109
D110
0111
10101
IN101
IN102
PH101
TR102
TR103
TR105
TR106
TR107
TR108
TS101
TS102
TS103
TS104
TS105
TS106
TS107
TS108
TS109
TS110
TS111
TS112
T8113
W101
w102
W103
X101
Part No.
ED-624903
ED-624903
ED-624903
ED-624903
ED-307572
ED-307572
ED-307572
ED-307572
ED-408651J
ED-307572
ED-307572
El-408645J
EM-408409J
EM-408410J
ET-403246J
ET-354414
ET-356336
ET-354364
ET-361736
ET-361736
ET-354414
ES-408641J
ES-408641J
ES-408641J
ES-408641J
ES-408641J
ES-408641J
ES-408641J
ES-408641J
ES-408641J
ES-408641J
ES-408641J
ES-408641J
ES-408641J
EW-408818J
EW-408819J
EW-408819J
El-408649J
Description
D SILICON H 182473
D SILICON H 182473
D SILICON H 182473
D SILICON H 182473
D SILICON H 1SS8131
D SILICON H 188131
D SILICON H 1SS131
D SILICON H 1SS131
D LED SEL2913K ORANGE
D SILICON H 1SS131
D SILICON H 188131
IC LC866008A-""" MXA1GE1
IND FL 10-MT-44GK CHARACTER
IND FL BJO3SGK DOUBLE
DETECTOR HC-377
TR DTC144ES
TR DTA114ES
TR DTC143TS
TR 2SC3576
TR 28C3576
TR DTC144ES
SW TACT EVQ 233 07K T05
SW TACT EVQ 233 07K TOS
SW TACT EVQ 233 07K TOS
SW TACT EVQ 233 07K T0S
SW TACT EVQ 233 07K TOS
SW TACT EVQ 233 07K TOS
SW TACT EVQ 233 07K TOS
SW TACT EVQ 233 07K T05
SW TACT EVQ 233 07K T05
SW TACT EVQ 233 07K T05
SW TACT EVQ 233 07K TO5
SW TACT EVQ 233 07K TO5
SW TACT EVQ 233 07K T05
CORD A6009 L=130 9P
CORD A6009 L=130 13P
CORD A6009 L=130 13P
OSC CE CST12.0MTW 12.000MHZ
7. GEQ P.C BOARD (TP-650)
Ref.No.
0201
D202
D203
D204
D205
D206
0207
FR201
FR202
18201
1B202
{C201
1c202
IC203
IC204
1C205
IC206
TR201
TR202
TR203
TR204
TR205
TR206
TR207
Part No.
ED-511907
ED-511907
ED-511907
ED-511907
ED-408807J
ED-408807J
ED-397103J
*ER-331619
#*ER-318248
EH-408650J
EH-408650J
El-408647J
El-408648J
El-408648J
El-400756J
El-408646J
EI-332259
ET-394735J
ET-394735J
ET-356336
ET-354414
ET-366581
ET-400965J
ET-353839
Description
D SILICON 1N4002 100/1.0A
D SILICON 1N4002 100/1.0A
D SILICON 1N4002 100/1.0A
D SILICON 1N4002 100/1.0A
D ZENER H HZS12C3
D ZENER H HZS12C3
D ZENER H HZS6A1
R FUSE H $10 ERD2FC 1/4W 39R0G
R FUSE H S10 ERD2FC 1/4W 47R0G
COMP R RYLS7J105 105J
COMP R RYLS7J105 105J
IC LC7522
IC LA3607
IC LA3607
IC NJM4558L-B
IC XR1091ECP
IC TC4052BP
TR 28C3792 TO5
TR 28C3792 TOS
TR DTA114ES
TR DTC144ES
TR 2SD1762 E,F
TR 2SB1357 E,F TOS
TR 2SA1317 STU
