C535 EB MANUAL 37
TECHNICAL DATA
6 Technical data
Type: condenser transducer, prepolarized
Polar pattern: cardioid
Frequency range: 20 … 20,000 Hz ±3 dB from published
curve
Sensitivity at 1,000 Hz:
7 mV/Pa ԑ0.7 mV/μbar
(–63 dBV, re 1 μbar)
Electrical Impedance: 200 ohms, ±20 % balanced
Recommended load impedance:
tRKPV
Hum Sensitivity (at 50 Hz): 4 μV/5 μT
Equivalent noise level to IEC 60268-4
(A-weighted): 21 dB-A
Maximum Sound Pressure (for 1 %
T.H.D. at 1,000 Hz into 600-ohm load):
with –14 dB attenuation:
80 Paԑ130 dB SPL
400 Paԑ144 dB SPL
Climatic Conditions
temperature range: min. –20° C, max. +60° C
Rel. humidity: 99 % (at +20° C
Powering: 9–52 V (acc. to IEC 61938)
Current consumption: approx. 1 mA
