19
4. As soon as the windscreen has dried,
replace it in the wire-mesh cap and
screw the wire-mesh cap onto the
transmitter CW.
6 Specifications
Carrier frequency range 710 to 865 MHz
Modulation FM
Audio bandwidth 40 to 20,000 Hz
Frequency stability (-10°C to +50°C) ±15 kHz
Rated deviation 15 kHz
T.H.D. at 1 kHz typ. 0.8%
Compander integrated
Signal/noise ratio 103 dB(A) typ.
RF output 10 mW typ.
Current consumption 70 mA typ.
Power requirement 2 x 1.5-V AA size batteries
Battery life 30 hours typ.
Audio input level for rated deviation 100 mV/1 kHz
Input impedance 220 kΩ
Size length: 258 mm (10 in.);
dia.: 40 mm (1.6 in.)
Net weight 245 g (8.7 oz.)
This product complies with the following standards:
EN60065:1998, EN301 489-9 v.1.1.1 (09-2000), and EN300 422-2 v.1.1.1 (07-2000).
