Akuvox R26C User Manual

 24
10Intercom‐Multicast






Sections Description
MulticastAudioReceiving TodisplayandconfiguretheMulticastsetting.
 Multicast Receiver Enable: Enable receiver
multicastfunction.
 Receiveraddress:Setupthemulticastaddress.
 Receiver port : setup the multicast address
port.
MulticastAudioSending Tosetupthemulticastparameters.
 Multicast Sending Enable: Enable sender
multicastfunction
 SendtoAddress:setupthemulticastaddress.
 Sendtoport:setupthemulticastaddressport.

Akuvox R26C Specifications

General

Audio	Built-in Microphone and Speaker
Ethernet	10/100 Mbps
Operating System	Linux
RS485	Yes
Relays	2
Operating Temperature	-10°C to 50°C
Installation	Wall-mounted
Weight	1.2 kg
Resolution	1024 x 600
Camera	2MP
Connectivity	Ethernet
Power Supply	PoE (802.3af)
Processor	Quad-core
Storage	8GB
Card Reader	MicroSD
Operating Humidity	10 ~ 90% (non-condensing)
Protocols	SIP
