Akuvox R27A User Manual

27
4.6. Network
4.6.1Basic

intooutgoingSIPmessagefordesignatedaccount.
UserAgent One can customize User Agent field in the SIP message; if
user agent is set to specific value, user can see the
information from PCAP. If user agent is not set by default,
users can see the company name, model number and
firmwareversionfromPCAP
Sections Description
LANPort TodisplayandconfigureLANPortsettings.
 DHCP: If selected, IP phone will get IP address, Subnet
Mask, Default Gateway and DNS server address from
DHCPserverautomatically.
 StaticIP:If selected,youhaveto setIP address,Subnet
Mask,DefaultGatewa yandDNSservermanually.


Akuvox R27A Specifications

General

Color	Yes
Video codecs	H.264, H.265
Number of buttons	15 buttons
Connectivity technology	Wired
Number of displays supported	-
Maximum number of cameras supported	1
Megapixel	2 MP
Sensor type	CMOS
Maximum frame rate	30 fps
Optical sensor size	1/2.7 \
Minimum illumination	0.1 lx
Supported video modes	1080p
Viewing angle, vertical	60 °
Maximum video resolution	1920 x 1080 pixels
Viewing angle, horizontal	116 °
Speaker power	2 W
Display diagonal	- \
Control type	Buttons
Product color	Black, Silver
International Protection (IP) code	IP65
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols	IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
LED type	IR
Power consumption	400 mA
Indoor unit power type	DC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Outdoor unit included	No

Weight and Dimensions

Depth	38 mm
Width	130 mm
Height	280 mm
