Akuvox R49G User Manual

R49G Guard Phone Administrator Guide
AKUVOX SMART INTERCOM www.akuvox.com
8
be assigned by the DHCP server with IP address, subnet
mask,gateway,and primary/ backup DNS server address automatically.
 Subnet Mask:If static IP mode is selected, then the IP address, subnet
mask, gateway, and DNS servers address will have to be manually
configured according to your actual network environment
 IP Address: set up the IP address if the static IP mode is selected.
 Subnet Mask: set up the subnet mask according to your actual network
environment.
 Default Gateway: set up the correct gateway default gateway according
to the IP address of the default gateway.
 LAN DNS1/2 Server: set up DNS (Domain Name Server) according to your
actual network environment. DNS 1 for primary DNS server while DNS2
fo the back DNS server. The guard phone will connect to the backup
server when the primary DNS server is unavailable.
3.4. Configure Device WIFI Connection
R49G guard phone supports Wi-Fi connection, you can configure the Wi-Fi
connection on the device. To do so you can slide down your finger twice on
device home screen and click on then click on Network&Internet >
Ethernet , switch on Wi-Fi and set up the Wi-Fi connection.

Akuvox R49G Specifications

General

Mounting	Desk
Handset type	Wired & Wireless handset
Product type	IP Phone
Product color	Black
Flash memory	8000 MB
Internal memory	2000 MB
Operating system version	Android 9.0
Operating system installed	Android
Dual-Tone Multi-Frequency (DTMF) modes	In-band
Caller ID	-
Lines quantity	- lines
Call log entries	600
Phonebook capacity	3000 entries
SIP registrar server	Yes
Display diagonal	7 \
Touchscreen type	Capacitive
Display resolution	1024 x 600 pixels
Front camera resolution (numeric)	2 MP
Voice codecs	G.722, G.723, G.729, PCMA
Video codecs	H.263, H.264, H.265, VP8
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3az
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	HTTP/HTTPS/FTP/TFTP/SNMP/DNS/SNTP/RTSP/SRTP/RTP/TCP/UDP/TLS/ICMP/DHCP/ARP/DNS-SRV/PNP/ZRTP
WAN connection type	RJ-45
Headset connectivity	3.5mm
USB Type-C ports quantity	1
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
Power consumption (typical)	12 W
Storage temperature (T-T)	10 - 90 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	-20 - 70 %
Operating relative humidity (H-H)	10 - 90 %
Number of handles included	- pc(s)

Weight and Dimensions

Depth	98 mm
Width	210 mm
Height	250 mm
Package depth	148 mm
Package width	254 mm
Package height	498 mm
Package weight	1720 g
