Akuvox R49G User Manual

R49G Guard Phone Administrator Guide
AKUVOX SMART INTERCOM www.akuvox.com
78
 Remote System Log: select “Enable” or “ Disable” if you wan to enable or
disable the remote system log.
 Remote System Server: enter the remote server address to receive the
the device And the remote server address will be provided by Akuvox
technical support.
18.2.PCAP for Debugging
PCAP in R49G guard phone is used to capture the data package going in and
out of the devices for debugging and troubleshooting purpose. You can set
up the PCAP on the device web Upgrade > Advanced > PCAP interface
properly before using it.
Parameter Set-up:
 PCAP: clickStart tab and Stop tab to capture the a certain range of data p
ackets before clicking Export tab to export the data packets to you Local
PC.
 PCAP Auto Refresh: select “Enable” or “ Disable” to turn on or turn off the
PCAP auto fresh function. If you set it as “Enable” then the PCAP will
continue to capture data packet even after the data packets reached its
1M maximum in capacity. If you set it as “ Disable” the PCAP will stop
data packet capturing when the data packet captured reaches the
maximum capturing capacity of 1MB.

Akuvox R49G Specifications

General

Mounting	Desk
Handset type	Wired & Wireless handset
Product type	IP Phone
Product color	Black
Flash memory	8000 MB
Internal memory	2000 MB
Operating system version	Android 9.0
Operating system installed	Android
Dual-Tone Multi-Frequency (DTMF) modes	In-band
Caller ID	-
Lines quantity	- lines
Call log entries	600
Phonebook capacity	3000 entries
SIP registrar server	Yes
Display diagonal	7 \
Touchscreen type	Capacitive
Display resolution	1024 x 600 pixels
Front camera resolution (numeric)	2 MP
Voice codecs	G.722, G.723, G.729, PCMA
Video codecs	H.263, H.264, H.265, VP8
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3az
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	HTTP/HTTPS/FTP/TFTP/SNMP/DNS/SNTP/RTSP/SRTP/RTP/TCP/UDP/TLS/ICMP/DHCP/ARP/DNS-SRV/PNP/ZRTP
WAN connection type	RJ-45
Headset connectivity	3.5mm
USB Type-C ports quantity	1
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
Power consumption (typical)	12 W
Storage temperature (T-T)	10 - 90 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	-20 - 70 %
Operating relative humidity (H-H)	10 - 90 %
Number of handles included	- pc(s)

Weight and Dimensions

Depth	98 mm
Width	210 mm
Height	250 mm
Package depth	148 mm
Package width	254 mm
Package height	498 mm
Package weight	1720 g
