AKYAPAK ASM - Machine Operation Procedures; Electrical Connections and Motor Control; Safety Systems and Usage

ASM
USER’S MANUEL
PAGE: 17
03.04-B1
8.4. SAFETY ROPE
At the time of the transportation the machine,the safety rope assembling to the surrounding the
machine should take out.May using after the assembling on the ground the safety rope.
The safety rope at 3 side of the machine must be assembling.
To strengthen the rope,must be use the angular arms.Screw this arms to the surround the
machine.
Place the rope inside the round of the pulley and tight them. To adjust the switch,the end of the
rope must stretch over showing below,and the button will pulling up and straight.For the security
machine is assembly the safety rope.
To stopping the machine,touch slowly the rope. To working the machine pull the button (Pull to
reset).
TO
PULL
RESET
