AL-KO Back Pack 150 - Intended Use; Before Driving

AL-KO / Back Pack Seite 7
Intended use
The load is to be stowed so that it is safe for traffic and so that it cannot fall down.
Maximum permitted payload: 150 kg!
Caution!
Have the installation performed by an authorised specialist workshop only.
Caution!
As user of this carrier you are responsible for the correct securing of the transported items. The position of the
straps and additional safety measures are different depending on the items being transported and the loading
weight. Check the secure hold of the transported items before every journey.
The legal license plate of the vehicle may possibly be covered by the load carrier or the load. If this is the case, the
license plate must be repeated on the light carrier .
Assembly
Perform the installation with at least one additional person.
The installation parts are marked with item numbers.
Tools and tightening torques
Bolt sizes
Torque strength class 8.8
M6
10 Nm
M8
25 Nm
M10
49 Nm
M12
86 Nm
Standard tightening torques for dry, non-greased mounting bolts (µ=0.14)
Values deviating from this are specified in special instructions.
Mounting the plug holder
This step is omitted if you have a trailer coupling on the vehicle!
1. Attach the plug holder to the chassis of the vehicle using the screw material
2. Secure the connector of the vehicle to the holder
3. Connect the 13-pin connector with the vehicle
Before driving
Check the attachment of the of the items being transported
(position of the straps, running board clamp)
Check the attachment of the load carrier to the vehicle
Connect the cable set with the 13-pin connector of the vehicle
Check all lights for proper function before starting the journey
Caution!
Remove the carrier when no luggage is being transported.
