GAS CONVERSION (NG to LPG; LPF to NG)
48
TURBULATOR CHANGE
The proper turbulator must be used on the burner for
particular gases such as NG or LPG. The following points
are followed for turbulator change:
Dismount the Multiblock (1).
Unscrew the bolts (2) between the burner body (12) and
connection body (13).
Burner is rotated via its hinges as seen in Figure 2.
Turbulator and gas line are changed in order to make the gas
conversion.
Figure 1
Figure 2
