49
Unscrew the centering bolt (4) and see the turbulator gas supply pipe (3) is freed. Pull the turbulator
gas supply pipe (3) upwards to unmount it from the connection body. Take the turbulator gas supply
pipe (3) out as seen in Figure 3.
Unscrew the electrode bolts (6) and
loosen the electrodes (5) (Figure 4).
Unscrew the 2 bolts (8) and dismount
the turbulator head. Replace the head
with the appropriate one (Figure 5).
6 5
Figure 4
87
Figure 5
4
3
Figure 3
