Wire the reader
Common Cable Connections
Wire Color Function
Red Power In
Black Ground
Shield
Shield Ground
Brown* Tamper Out
Yellow* Beeper Control
Blue* Green LED Control
https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Access_Control/Access_Control_Entry%2F%2FExit_De…
Updated: Mon, 08 Apr 2024 20:56:52 GMT
2
